HP Pavilion x360 15 User Manual

e. Disconnect both ends of the TouchScreen board cable (2) from the two connectors on
the TouchScreen board.
f. Release the adhesive strip (1) that secures the display panel cable connector to the display panel.
g. Disconnect the display panel cable (2) from the display panel.
h. Remove the display panel assembly (3).
The display panel assembly is available using the following spare part numbers:
●
924530-001 – 15.6-in, FHD, WLED, BrightView, TouchScreen equipped with an FHD
infrared camera
●
925711-001 – 15.6-in, FHD, WLED, BrightView, TouchScreen equipped with an HD non-
infrared camera
●
924531-001 – 15.6-in, HD, WLED, AntiGlare, TouchScreen equipped with an HD non-
infrared camera
50 Chapter 5 Removal and replacement procedures
