d. Remove the TouchScreen board (2).
The TouchScreen board is available using spare part number 929145-001 and includes the G-
sensor board.
5. If it is necessary to replace the webcam/microphone module:
NOTE: The webcam/microphone module can be removed and replaced without removing the display
assembly from the base enclosure.
a. Remove the display panel assembly.
b. Disconnect the webcam/microphone module cable (1) from the webcam/microphone module.
52 Chapter 5 Removal and replacement procedures
