3. Remove the following:
(1) Rubber screw plugs on the front edge of the base enclosure
(2) Oblong screw cover in the middle of the base enclosure
(3) Rear rubber foot strip
The rubber screw plugs, oblong screw cover, and the rear rubber foot strip are available in the Rubber
Kits, spare part numbers 856021-001 (for use on computers models in modern gold nish)
and 856020-001 (for use on computers models in natural silver nish).
4. Remove the ve Phillips PM2.0×5.0 screws (1) and the ve Phillips PM2.4×5.7 screws (2) that secure
the keyboard/top cover to the base enclosure.
5. Turn the computer right side up with the front toward you.
Component replacement procedures 37
