1–10 Hardware and Software Guide
Component ID
Right-Side Components
Ports
Component Description
1
1394 port (select
models only)
Connects an optional 1394a device
such as a scanner, a digital camera,
or a digital camcorder.
2
USB port* Connects an optional USB device.
3
Expansion port 2
†
Connects the notebook to an optional
docking device.
*The notebook has 4 USB ports. The other USB ports are on the left side
and the rear of the notebook.
†
The notebook has only one expansion port. The term
expansion port 2
describes the type of expansion port. For expansion port signal information,
refer to “Expansion Port 2 Input/Output Signals” in Chapter 17,
“Specifications.”
