Battery
Table 5-1 Battery description and part number
Description Spare part number
Battery, 3 cell, 45 Whr, 3.92 Ahr L32656-002
Before removing the battery, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 34).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 34).
3. Remove the bottom cover (Bottom cover on page 36).
Remove the battery:
1. Remove the two Phillips M2.0 × 4.0 screws (1) that secure the battery to the computer.
2. Lift the top (connector side) of the battery up to an approximate 45° angle (2), and then remove the
battery from the computer (3).
Reverse this procedure to install the battery.
Component replacement procedures 35
