HP ProBook 430 G7 User Manual

1 Product description
Table 1-1 Product components and their descriptions
Category Description
Product Name HP ProBook 430 G7 Notebook PC
Processors 10th generation, Intel® Core™ (15 W)
i7-10510U, 1.8 GHz/4.9 GHz, quad core turbo, 8 MB L3 cache; Intel UHD Graphics 620
i5-10210U, 1.6 GHz/4.2 GHz, quad core turbo, 6 MB L3 cache; Intel UHD Graphics 620
i3-10110U, 2.1 GHz/4.1 GHz, dual core turbo, 4 MB L3 cache; Intel UHD Graphics 620
Graphics Supports HD decode, DX12, HDMI 1.4b up to 4K @ 30 Hz, HDCP 2.3 via DisplayPort™ up to 4K @ 60 Hz
Integrated Intel UMA Graphics
Intel UHD Graphics 620
Supports 3 independent displays when on the HP USB-C Dock G4; Max resolution = 4K @ 30Hz (DisplayPort
1) or 4K @ 30Hz (DisplayPort 2)
Supports 3 independent displays when on the HP Thunderbolt™ Dock 120 W (using USB-C); Max resolution
= 4K @ 30 Hz (DisplayPort 1) or 4K @ 30 Hz (DisplayPort 2)
Panel 33.8 cm (13.3 inch), HD (1366 × 768), LED backlight, antiglare, SVA, 220 nits, 45% CG, eDP, ultraslim
No camera
HD camera
HD + IR camera
HD camera, for WWAN
33.8 cm (13.3 inch), FHD (1920 × 1080), LED backlight, antiglare, UWVA, eDP
No camera, slim, 45% CG, 250 nits
HD camera, slim, 45% CG, 250 nits
HD + IR camera, slim, 45% CG, 250 nits
HD camera, for WWAN, at, 72% CG, eDP + PSR, 1000 nits, HD camera, privacy
Touch screens; 33.8 cm (13.3 inch), 45% CG, eDP, two WLAN antennas
HD (1366 × 768), SVA, ultraslim, HD camera, 220 nits
FHD (1920 × 1080), UWVA, slim, HD camera, 250 nits
FHD (1920 × 1080), UWVA, slim, for WWAN, HD camera, 250 nits
Memory Two memory module slots supporting up to 32 GB of RAM
Supports dual-channel memory
PC4-2666, DDR4 SODIMMs
Supports the following congurations:
1

HP ProBook 430 G7 Specifications

General

Graphics	Intel UHD Graphics
Weight	Starting at 1.49 kg
Battery	HP Long Life 3-cell, 45 Wh Li-ion
Processor	Intel Core i5-10210U, i5-10510U, i3-10110U
Display	13.3" diagonal HD (1366 x 768) or FHD (1920 x 1080)
RAM	Up to 32 GB DDR4-2666
Storage	Up to 1 TB PCIe NVMe SSD
Ports	USB 3.1 Gen 1, HDMI 1.4b, RJ-45, headphone/microphone combo
Operating System	Windows 10 Pro
Wireless	Intel Wi-Fi 6 AX201 (2x2) and Bluetooth 5
