HP ProBook 445R G6 - Product Description

1 Product description
Table 1-1 Product components and their descriptions
Category Description
Product Name HP ProBook 445R G6 Notebook PC
Processors AMD Ryzen™ processors
Ryzen 5-3500U (2.1 GHz, turbo up to 3.7 GHz), 6 MB L2 + L3 cache, 2400 MHz, quad core, 15 W; Radeon™
Vega 8 Graphics
Ryzen 3-3200U (2.6 GHz, turbo up to 3.5 GHz), 5 MB L2 + L3 cache, DDR4-2400 MHz, dual core, 15 W;
Radeon Vega 3 Graphics
Graphics Integrated Intel UMA Graphics
Integrated with shared video memory (see Processor category)
Supports HD decode, DX12, HDMI 1.4b up to 4K @ 30 Hz
Supports 4 independent displays when on the HP USB-C Dock G4; Max resolution = 4K @ 30 Hz
(DisplayPort™ 1) or 4K @ 30 Hz (DisplayPort 2)
Supports 4 independent displays when on the HP Thunderbolt Dock (using USB-C); Max resolution = 4K @
30 Hz (DisplayPort 1) or 4K @ 30 Hz (DisplayPort 2)
Supports 4 independent displays when on the HP USB-C Mini Dock; Max. resolution = 4K @ 30 Hz (HDMI) or
1920 × 1080 @ 60 Hz (VGA)
Supports 4 independent displays when on the HP USB-C Universal Dock; Max. resolution = 4K @ 30 Hz
(DisplayPort 1) or 4K @ 30 Hz (DisplayPort 2)
Panel 35.6 cm (14.0 in), HD (1366 × 768), LED backlight, 220 nits, 45% CG, eDP, slim, antiglare, SVA, narrow
bezel
No camera
HD camera, 1 WLAN antenna
HD camera, 2 WLAN antennas
HD+ IR camera, 2 WLAN antennas
35.6 cm (14.0 in), FHD (1920 × 1080), LED backlight, 220 nits or 250 nits, 45% CG, eDP, slim, antiglare,
UWVA, narrow bezel
No camera
HD camera, 1 WLAN antenna
HD camera, 2 WLAN antennas
HD+ IR camera, 2 WLAN antennas
Memory Two customer-accessible memory module slots supporting up to 16 GB of RAM
Supports dual-channel memory
PC4-2400, DDR4 SODIMMs
Supports the following congurations:
