M.2 solid-state drive
Table 5-4 Solid-state drive descriptions and part numbers
Description Spare part number
512 GB, PCIe, TLC L59045-001
512 GB, PCIe, value L59046-001
256 GB, PCIe L59044-001
128 GB, SATA-3, TLC L59043-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 31).
3. Remove the bottom cover (Bottom cover on page 32).
4. Remove the battery (Battery on page 40).
Remove the solid-state drive:
1. Remove the Phillips M2.0 × 2.5 screw (1) that secures the solid-state drive to the computer.
2. Remove the solid-state drive (2) by pulling the module away from the slot at an angle.
Reverse this procedure to install the solid-state drive.
