HP ProBook 445R G6 User Manual

Heat sink
NOTE: All heat sink spare part kits include replacement thermal material.
Table 6-4 Heat sink description and part number
Description Spare part number
Heat sink L52217-001
Before removing the heat sink, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 31).
3. Remove the bottom cover (Bottom cover on page 32).
4. Remove the battery (Battery on page 40).
Remove the heat sink:
▲ To remove the heat sink:
a. In the order indicated on the heat sink, loosen the four captive Phillips screws (1) that secure the
heat sink to the system board.
b. Lift the heat sink from the system board (2).
44 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP ProBook 445R G6 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD Ryzen 3/5/7
Graphics	AMD Radeon Vega 8
Display	14-inch, 1920 x 1080
RAM	Up to 32GB DDR4
Storage	Up to 1 TB HDD
Weight	1.6 kg
Battery	3-cell, 45 Wh Li-ion
Ports	2 x USB 3.1, 1 x USB-C, HDMI, RJ-45, headphone/microphone combo jack
Wireless	802.11ac, Bluetooth 4.2
