HP ProBook 445R G6 User Manual

Hard drive
Table 5-5 Hard drive and Hard Drive Hardware Kit descriptions and part numbers
Description Spare part number
Hard drive, 1 TB, 5400 rpm, 7 mm L30422-001
Hard drive, 500 GB, 7200 rpm, 7 mm 703267-001
Hard Drive Hardware Kit (includes hard drive cover and connector) L44510-001
Hard drive cover L45781-001
Before removing the hard drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 31).
3. Remove the bottom cover (Bottom cover on page 32).
4. Remove the battery (Battery on page 40).
Remove the hard drive:
1. Release the ZIF connector (1), and then disconnect the hard drive cable from the system board (2).
2. Remove the two Phillips M2.0 × 4.0 screws (3) that secure the hard drive to the computer.
3. Use the tab to lift the hard drive from the bay (4).
Component replacement procedures 37

HP ProBook 445R G6 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD Ryzen 3/5/7
Graphics	AMD Radeon Vega 8
Display	14-inch, 1920 x 1080
RAM	Up to 32GB DDR4
Storage	Up to 1 TB HDD
Weight	1.6 kg
Battery	3-cell, 45 Wh Li-ion
Ports	2 x USB 3.1, 1 x USB-C, HDMI, RJ-45, headphone/microphone combo jack
Wireless	802.11ac, Bluetooth 4.2
