Cable Kit

Table 3-3 Cable Kit components and their descriptions

Item Description Spare part number

Cable Kit, includes the following parts: L52216-001

(1) Power/USB board cable

(2) Card reader board cable

(3) Fingerprint sensor cable

Cable Kit 21
