HP ProBook 445R G6 User Manual

Power connector cable
Table 6-11 Power connector cable description and part number
Description Spare part number
Power connector cable L01048-001
Before removing the power connector cable, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 31).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 31).
3. Remove the bottom cover (Bottom cover on page 32).
4. Remove the battery (Battery on page 40).
5. Remove the display (Display assembly on page 57).
Remove the power connector cable:
1. Disconnect the cable from the system board (1).
2. Use a tool (2) to lever the connector up and out of the computer (3).
Reverse this procedure to install the power connector cable.
64 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP ProBook 445R G6 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD Ryzen 3/5/7
Graphics	AMD Radeon Vega 8
Display	14-inch, 1920 x 1080
RAM	Up to 32GB DDR4
Storage	Up to 1 TB HDD
Weight	1.6 kg
Battery	3-cell, 45 Wh Li-ion
Ports	2 x USB 3.1, 1 x USB-C, HDMI, RJ-45, headphone/microphone combo jack
Wireless	802.11ac, Bluetooth 4.2
