12. Slide the keyboard back toward the display (1), and then rotate it forward (2) to gain access to the
keyboard cable connector.
NOTE: Refer to the illustration that most closely matches your computer.
CAUTION: Do not rip the keyboard cable.
– or –
Slide the keyboard back toward the display (1), and then rotate it to the right side (2) to gain access
to the keyboard cable connector.
CAUTION: Do not rip the keyboard cable.
Replacing the hard drive 47

HP ProBook 4525s - Notebook PC Specifications

General

Chipset	AMD M880G
Memory	Up to 8 GB DDR3
Graphics	ATI Mobility Radeon HD 4250
Operating System	Windows 7 Professional
Wireless	802.11b/g/n
Webcam	2 MP webcam
Processor	AMD Turion II Dual-Core Mobile Processor, AMD Athlon II Dual-Core Processor
Display	15.6-inch diagonal LED-backlit HD anti-glare
Storage	320 GB
Optical Drive	DVD+/-RW SuperMulti DL LightScribe
Battery	6-cell Lithium-Ion
Bluetooth	Yes
Audio	Integrated stereo speakers
Ports	3 USB 2.0
