HP ProBook 4525s - Notebook PC

13. Release the ZIF connector (1) to which the keyboard cable is attached, disconnect the keyboard
cable (2) from the system board by pulling upward, and then remove the keyboard from the
computer (3).
NOTE: Refer to the illustration that most closely matches your computer.
48 Chapter 5 Drives
