Modem module cable
NOTE: The modem module cable is included in the Cable Kit, spare part numbers 613352-001.
Before removing the modem module cable, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 72).
5.
Remove the following components:
a.
Bluetooth module (see
Bluetooth module on page 74)
b.
Mass storage device (see
Mass storage device on page 75)
c.
Optical drive (see
Optical drive on page 86)
d.
Keyboard (see
Keyboard on page 88)
e.
Switch cover (see
Switch cover on page 94)
f.
Fan (see
Fan on page 102)
g.
Heat sink (see
Heat sink on page 104)
h.
Palm rest (see
Palm rest on page 98)
i.
TouchPad (see
TouchPad on page 100)
j.
Display assembly (see
Display assembly on page 109)
k.
Top cover (see “Top cover” on page 4-49)
l.
ExpressCard assembly (see
ExpressCard assembly on page 126)
m.
Speaker assembly (see
Speakers on page 130)
n.
Card reader/USB board (see
Card reader/USB board on page 134)
o.
System board (see
System board on page 136)
Remove the modem module cable:
1. Release the RJ-11 connector (1) from the clip built into the base enclosure.
2. Release the modem module cable from the clips (2) and routing channel built into the base
enclosure.
142 Chapter 4 Removal and replacement procedures
