Bluetooth module cable
NOTE: The Bluetooth module cable is included in the Cable Kit, spare part numbers 613352-001.
Before removing the Bluetooth module cable, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 72).
5.
Remove the following components:
a.
Bluetooth module (see
Bluetooth module on page 74)
b.
Mass storage device (see
Mass storage device on page 75)
c.
Optical drive (see
Optical drive on page 86)
d.
Keyboard (see
Keyboard on page 88)
e.
Switch cover (see
Switch cover on page 94)
f.
Palm rest (see
Palm rest on page 98)
g.
TouchPad (see
TouchPad on page 100)
h.
Display assembly (see
TouchPad on page 100)
i.
Top cover (see
Top cover on page 121)
Remove the Bluetooth module cable:
1. Disconnect the Bluetooth module cable (1) from the system board.
132 Chapter 4 Removal and replacement procedures
