HP ProCurve 2610 Installation And Getting Started Guide

2 – Index
Index
CLI prompt, console
displaying … 2-27
configuration … 2-17
checking when troubleshooting … 4-3
DHCP/Bootp … 3-1
IP address … 3-2
IP address, manually … 3-2
manager password … 3-2
restoring factory defaults … 1-10, 4-12
subnet mask … 3-2
Switch Setup screen … 3-2
connecting the switch to a power source … 2-16
connecting the switch to an EPS … 2-24–2-25
connecting the switch to an RPS/EPS … 2-22–2-24
connector specifications … A-3
console
checking messages during
troubleshooting … 4-10
displaying the CLI prompt … 2-27
features … 2-26
how to connect in-band … 2-26
how to connect out-of-band … 2-26
serial cable connection … 2-27
Switch Setup screen … 3-2
Telnet access … 3-5
terminal configuration … 2-26
console port
definition … 1-11
location on switch … 1-4
cross-over cable
pin-out … B-7
D
deleting passwords … 1-10
description
back of switch … 1-11
front of switch … 1-4
LEDs … 1-5
switch … 1-1
desktop switch
sample topology … 2-28, 2-32
DHCP
automatic switch configuration … 3-1
for in-band access … 2-26
diagnostic tests … 4-10
checking the console messages … 4-10
checking the LEDs … 4-10
end-to-end connectivity … 4-11
testing the switch only … 4-10
testing twisted-pair cabling … 4-11
downloading new switch software … 4-13
E
electrical specifications, switch … A-1
EMC regulatory statements … C-8
environmental specifications
BTU ratings … A-2
environmental specifications, switch … A-2
EPS … 2-19
connecting to a switch … 2-24–2-25
EPS input port … 1-12
F
factory default configuration, restoring … 1-10, 4-12
Fan Status LED … 1-6
Fault LED … 1-5
behavior during self test … 2-8
behaviors … 1-5
flashing definition … 1-7–1-8
location on switch … 1-4
showing error conditions … 4-4
features
console … 2-26
switch … 1-12
fiber-optic cables … B-2
1000Base-BX … B-2
1000Base-LH … B-2
1000Base-T … B-2
flashing LEDs
error indications … 4-4
front of switch … 1-4
10/100Base-TX ports … 1-4
Clear button … 1-10
description … 1-4
LEDs … 1-5
network ports … 1-5
Reset button … 1-10
full-duplex fixed configuration
effects on network connections … 4-1

HP ProCurve 2610 Specifications

General

Switching Capacity	12.8 Gbps
Forwarding Rate	9.5 Mpps
MAC Address Table Size	8000 entries
Layer	Layer 2
RAM	64 MB
Flash Memory	16 MB
Jumbo Frame Support	Yes
Manageable	Yes
Operating Humidity	15% to 95% non-condensing
Ports	24 x 10/100
VLANs	256
Management	Web, CLI, SNMP
Power Supply	Internal
Operating Temperature	0°C to 40°C
Dimensions (W x D x H)	17.42 x 12.73 x 1.73 in
