HP ProCurve 2824 User Manual

2-1
Installing the Switch
2
Installing the Switch
The HP ProCurve Switch 2800 Series devices are easy to install. They come
with an accessory kit that includes the brackets for mounting the switch in a
standard 19-inch telco rack, in an equipment cabinet, and with rubber feet that
can be attached so the switch can be securely located on a horizontal surface.
The brackets are designed to allow mounting the switch in a variety of
locations and orientations. This chapter shows how to install the switch.
Included Parts
The Switch 2800 Series devices have the following components shipped with
them:
■ HP ProCurve Switch 2800 Series Installation and Getting Started Guide
(J4903-90001), this manual
■ HP ProCurve Product Documentation CD ROM
(contains PDF file copies of the documentation for the Switch 2800 Series
devices, including the Management and Configuration Guide, and for
most other HP ProCurve switches)
■ HP ProCurve Manager - CD ROM and booklet
■ Console cable
■ Customer Support/Warranty booklet
■ Accessory kits
(5064-5085) for Switch 2824 (5069-5705) for Switch 2848
two mounting brackets two mounting brackets*
four 8-mm M4 screws to attach the
mounting brackets to the switch
eight 8-mm M4 screws to attach the
mounting brackets to the switch
four 5/8-inch number 12-24 screws to
attach the switch to a rack
four 5/8-inch number 12-24 screws to attach
the switch to a rack
four rubber feet four rubber feet
* These mounting brackets differ from the 5064-5085 mounting brackets by being longer to
support the increased depth of the 2848 product (compared to the 2824).

HP ProCurve 2824 Specifications

General

Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Layer	Layer 2
Rack Mountable	Yes
Jumbo Frame Support	Yes
Management	CLI, SNMP
Features	Link Aggregation, QoS
Dimensions	1.7 inches
Ports	24 x 10/100/1000
