HP ProCurve 2824 User Manual

2-10
Installing the Switch
Installation Procedures
Installing the Switch
2. Check the LEDs on the switch as described below.
When the switch is powered on, it performs its diagnostic self test. Self
test takes approximately 50 seconds to complete.
LED Behavior:
During the self test:
• Initially, all the status, LED Mode and port LEDs are on for most of
the duration of the test.
• Most of the LEDs go off and then may come on again during phases
of the self test. For the duration of the self test, the Test LED stays on.
Power
Fault
hp procurve
switch
2824
J4903A
Console
10/100/1000-T Ports (1 - 20)  Ports are IEEE
A
Spd mode: off = 10 Mbps, flash = 100 Mbps, on = 1000 Mbps
LED
Mode
1
Status
Clear
Reset
9
7
Fan
RPS
Test
Lnk
Act
FDx
Spd
4
6
8
10
14
16
1
5
7
911
12
13
15
31
2
Switch 2824
Test LED
Power and
Fault LEDs
Switch port LEDs
LED
Mode
Clear
Reset
4
5
2
5
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
Spd mode: off = 10 Mbps, flash = 100 Mbps, on = 1000 Mbps
10/100/1000Base-T Ports (1 - 44, 45T, 46T, 47T,
1
15 17
16
18
Power
Fault
hp procurve
switch
2848
J4904A
1
2
3
Spd
Lnk
Act
FDx
Test
RPS
Status
Fan
Switch port LEDs
Power and
Fault LEDs
Switch 2848
Test LED

HP ProCurve 2824 Specifications

General

Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Layer	Layer 2
Rack Mountable	Yes
Jumbo Frame Support	Yes
Management	CLI, SNMP
Features	Link Aggregation, QoS
Dimensions	1.7 inches
Ports	24 x 10/100/1000
