Configuring Username and Password Security

Front Panel Security

3. Release the Reset button and wait for about one second for the Self-Test

LED to start flashing.

Reset Clear

Self

Te st

4. When the Self-Test LED begins flashing, release the Clear button

Reset Clear

Self

Te st

This process restores the switch configuration to the factory default settings.

2-12
