Environmental
Connectors
■ The 10/100 Mbps RJ-45 twisted-pair port is compatible with the
IEEE 802.3u 100Base-TX and IEEE 802.3 Type 10Base-T standards.
Note: To provide Power over Ethernet to the access point, all 4 pairs of
wires must be connected for any network cable attached to this port.
Safety
Complies with:
■ IEC 60950-1: 2001
■ EN 60950-1: 2002
■ UL 60950-1 1st Ed.
■ UL 2043
■ CAN/CSA-C22.2 No. 60950-1-03
EMC Compliance (Class B)
Complies with:
■ FCC Part 15.107 and 15.109
■ ICES-003 (Canada)
■ VCCI
Operating Non-Operating
Temperature: 0° C to 50° C (32° F to 122° F) PoE mode
0° C to 40° C (32° F to 104° F) w/adapter
-40° C to 70° C (-40° F to 158° F)
Relative humidity:
(non-condensing)
5% to 95% 5% to 95%
Maximum altitude: 3.05 Km (10,000 ft) 4.6 Km (15,000 ft)
