16. Lock any security devices that were disengaged when the computer access panel was removed.
17. Reconfigure the computer, if necessary.
Drive positions
1 5.25-inch half-height drive bay (optical drive shown)
2 5.25-inch half-height drive bay
3 3.5-inch drive bay for optional drive (media card reader shown)
4 Primary 3.5-inch internal hard drive bay
5 Secondary 3.5-inch internal hard drive bay
NOTE: The drive configuration on your computer may be different than the drive configuration shown above.
To verify the type and size of the storage devices installed in the computer, run Computer Setup.
20 Chapter 2 Hardware upgrades
