7. If you are installing an optical drive, install one black M3 metric mounting screw in the front
upper screw hole on the right side of the drive.
NOTE: HP has supplied three extra M3 mounting screws on the front of the chassis behind the
bezel. Refer to
Installing and removing drives on page 21 for an illustration of the extra mounting
screws location. When replacing an optical drive, transfer the M3 mounting screw from the old
drive to the new one.
CAUTION: Use only 5-mm long screws as mounting screws. Longer screws can damage the
internal components of the drive.
8. Slide the drive into the drive bay (1) and install the two M3 mounting screws in the side of the
drive (2) to secure it in place.
24 Chapter 2 Hardware upgrades
