4. Install 6-32 guide screws in the holes on each side of the device.
NOTE: HP has supplied four extra 6-32 guide screws on top of the drive cage. Refer to
Drives
on page 32 for an illustration of the extra guide screws location.
When replacing a device, transfer the four 6-32 guide screws from the old device to the new one.
5. Rotate the drive cage to its upright position.
36 Chapter 4 Removal and replacement procedures: Small Form Factor
