Removal and Replacement Procedures
3. Remove the server blade from the server blade enclosure:
a. Press the release button (1).
b. Open the lever (2).
c. Grasp the lever and slide the server blade from the enclosure (3). Place a hand under
the server blade to support it as you remove it from the enclosure.
NOTE: When removing a server blade, it is not necessary to remove the blade sleeve from the
enclosure.
Figure 2-1: Removing the server blade from the blade sleeve in the
server blade enclosure
d. Place the server blade on a flat, level surface.
CAUTION: Always populate server blade enclosure bays with either a server blade or server
blade blank. Operating the enclosure without a server blade or server blade blank results in
improper airflow and improper cooling that can lead to thermal damage.
Reverse steps 1 through 3 to install and power up a server blade. Server blades are set to
power up automatically upon insertion. If you have changed this setting, use the Power
On/Standby button or iLO Virtual Power Button feature to power up the server blade.
For more information about iLO, refer to the Integrated Lights-Out User Guide.
HP ProLiant BL30p Server Blade Maintenance and Service Guide 2-5
