HP ProLiant BL30p

Removal and Replacement Procedures
Removing the Blade Sleeve Board
To remove the blade sleeve board:
1. With the blade sleeve on a flat surface, remove the access panel from the blade sleeve.
Figure 2-27: Removing the blade sleeve access panel
2. Loosen the thumbscrews on the outside of the blade sleeve (1).
3. Remove the screws from the blade sleeve board (2), and remove the blade sleeve (3).
Figure 2-28: Removing the blade sleeve board
Reverse steps 1 through 3 to replace the blade sleeve board.
HP ProLiant BL30p Server Blade Maintenance and Service Guide 2-27
