HP ProLiant BL30p

Removal and Replacement Procedures
Power Converter Module
To remove the power converter module:
1. Power down the server blade and remove it from the server blade enclosure. Refer to the
“Server Blad e Preparation” section in this chapter.
2. Remove the FC adapter. Refer to “Dual Port Fibre Channel Adapter” in this chapter.
3. Remove the NIC riser board. Refer to “NIC Rise r Board” in this chapter.
4. Release the two clips securing the power converter module to the system board (1).
5. Remove the power converter module (2).
Figure 2-22: Removing the Power Converter Module
Reverse steps 1 through 5 to replace the power converter module.
