HP ProLiant BL30p

Removal and Replacement Procedures
Fan Assembly
To remove the fan assembly:
1. Power down the server blade and remove it from the server blade enclosure. Refer to the
“Server Blad e Preparation” section in this chapter.
2. Lay the server blade on a flat, stable surface.
3. Disconnect the two fan cables from the system board.
Figure 2-18: Disconnecting fan cables
4. Squeeze the retaining clips on the fan assembly (1) and lift the fan assembly from the
retaining brackets (2).
Figure 2-19: Removing the fan assembly
Reverse steps 1 through 4 to replace the fan assembly.
HP ProLiant BL30p Server Blade Maintenance and Service Guide 2-17
