HP ProLiant BL30p

Removal and Replacement Procedures
Figure 2-6: Removing a second hard drive
IMPORTANT: Be sure the hard drive label is on the top side of the hard drive when installed in the
drive cage assembly.
Figure 2-7: Replacing a hard drive
2-8 HP ProLiant BL30p Server Blade Maintenance and Service Guide
