HP ProLiant BL30p

Removal and Replacement Procedures
2. Remove the processor (2).
Figure 2-14: Removing the processor
To replace the processor:
CAUTION: When installing the processor into the socket, be sure that the locking
lever is raised to avoid damaging pins.
1. Align the processor and install the processor into the socket (1).
2. Close the processor locking lever (2).
Figure 2-15: Replacing the processor
2-14 HP ProLiant BL30p Server Blade Maintenance and Service Guide
