Installing hardware options
HP ProLiant DL585 Server User Guide 4-3
Figure 4-1: Locating the processor memory boards
Table 4-1: Processor memory boards
Item Description
1 Processor memory board slot 1 (processor)
2 Processor memory board slot 2 (boot processor)
3 Processor memory board slot 3 (air baffle)
4 Processor memory board slot 4 (air baffle)
