HP ProLiant DL585 - Installing a Processor Memory Board

Installing hardware options
4-4 HP ProLiant DL585 Server User Guide
Installing a processor memory board
1. Power down the server. Refer to “Powering down the server” in Chapter 2,
“Server operations.”
2. Extend the server from the rack. Refer to “Extending the server from the rack” in
Chapter 2, “Server operations.”
3. Remove the access panel. Refer to “Removing the access panel” in Chapter 2,
“Server operations.”
4. Remove the air baffle.
NOTE: Do not discard the air baffle. Store it for possible future use.
5. Install the new processor memory board.
Figure 4-2: Installing a processor memory board
6. Reinstall the access panel.
7. Restore the server to its operating position in the rack.
8. Power up the server.
NOTE: The ROM sets the processing frequency during POST.
