Hardware options installation 68
o
Slot 3
8. Align the PCI riser board with the corresponding connector on the system board, and then press
down the riser cage.
9. Tighten the two screws to secure the cage.
IMPORTANT: The server does not power up if the PCI riser cage is not seated properly.
10. Install the access panel (on page 19).
11. Install the server into the rack.
12. Power up the server (on page 15).
M.2 SSD enablement option
To install the component:
1. Power down the server (on page 15).
