HP ProLiant DL785

DescriptionItem
DIMM slot 6C6
DIMM slot 7D7
DIMM slot 8D8
Processor socket9
Rear panel components
DescriptionItem
NIC connector 11
Keyboard connector2
USB connector3
Video connector4
Serial connector5
iLO 2 connector6
Mouse connector7
NIC connector 28
Power supply 19
Power supply 210
Power supply 311
Redundant power supply 4 (optional)12
Redundant power supply 5 (optional)13
Redundant power supply 6 (optional)14
PCI Express or HTx expansion slots15
T-15 Torx screwdriver16
Fan 417
14 Component identification
