HP ProLiant DL785

NOTE: The T-15 Torx screwdriver is shipped with the server and can be located on the
rear panel (“Rear panel components” (page 14)).
3. Lift up on the hood latch and remove the access panel.
4. After installing hardware options, replace the access panel. Be sure that the panel is securely
locked into place before powering up the server.
Accessing the System Insight Display
IMPORTANT: When viewing the Systems Insight Display LEDs (“System Insight Display LEDs”
(page 10)), leave the server powered on. The Systems Insight Display LEDs are cleared when
the server is powered off.
To access the SID:
1. Push the SID.
Accessing the System Insight Display 33
