HP ProLiant DL785

Combo PCIe/HTx I/O backplane
DescriptionItem
HyperTransport non-hot-plug expansion slot 84
PCI Express x4 non-hot-plug expansion slot 75
PCI Express x4 non-hot-plug expansion slot 66
PCI Express x16 non-hot-plug expansion slot 57
PCI Express x4 non-hot-plug expansion slot 48
PCI Express x4 non-hot-plug expansion slot 39
PCI Express x4 non-hot-plug expansion slot 210
PCI Express x8 non-hot-plug expansion slot 111
SPI board components
SPI (core I/O) board
DescriptionItem
BBWC module connections1
Serial peripheral interface board2
System battery3
System maintenance switch (SW6)
The system maintenance switch (SW6) is an eight position switch that is used for system
configuration. The default position for all eight positions is Off (closed).
FunctionSwitchDescriptionPosition
iLO 2 security is enabledOffiLO 2 security1
iLO 2 security is disabledOn
18 Component identification
