8. Install the battery, if applicable.
a. Install the battery pack into the server.
b. Plug the battery cable (supplied in the battery pack kit) into the battery pack.
c. Route the cable and connect it to the cache module.
NOTE: After installing a battery pack, you might see a POST message during reboot
indicating that the array accelerator (cache) is temporarily disabled. This is normal, because
the new battery pack probably has a low charge. You do not need to take any action, because
the recharge process begins automatically when the battery pack is installed. The controller
operates properly while the battery pack recharges, although the performance advantage
of the array accelerator are absent. When the battery pack is charged to a satisfactory level,
the array accelerator is automatically be enabled.
56 Hardware options installations
