HP ProLiant DL785

DescriptionItem
Hard drive bay 4 right9
Hard drive bay 5 right10
Hard drive bay 6 right11
Hard drive bay 7 right12
Hard drive bay 8 right13
Hard drive bay 1 left (optional)not shown
Hard drive bay 2 left (optional)not shown
Hard drive bay 3 left (optional)not shown
Hard drive bay 4 left (optional)not shown
Hard drive bay 5 left (optional)not shown
Hard drive bay 6 left (optional)not shown
Hard drive bay 7 left (optional)not shown
Hard drive bay 8 left (optional)not shown
Processor memory cell 114
Processor memory cell 215
Processor memory cell 3
1
16
Processor memory cell 4
1
17
Processor memory cell 5
1
18
Processor memory cell 6
1
19
Processor memory cell 720
Processor memory cell 821
1 Occupied by a cell filler in four-processor servers.
8 Component identification
