Component identification 8
• LFF
Item Description
1
Media/Drive cage bay
2
SAS/SATA drive (6)
3
Serial number/iLO information pull tab*
4
Optical drive
5
USB connectors (4)
*The serial number/iLO information pull tab is double-sided. The top side shows the server serial number, and the reverse
side shows the default iLO account information. The same information is printed on a label attached to the chassis.
Front panel LEDs and buttons
