Connecting a serial device
Some serial devices may require
a DB9 connector. Avai
la
ble options from HP are RJ-50 to DB9 adapter cables
(either 1 meter or 2 me
ters in length) as shown belo
w.
NOTE:
The serial ports c
an be configu
red as 5V
or 12V powered ser
ial ports. Ref
er to
Configuri
ng powered
serial port
s
on page
59
for more information.
