4. Remove the screws (1) from the USB assembly, and then rotate the assembly up and off the computer
(2).
NOTE: The screws you must remove differs depending on which USB assembly you are removing:
On the top USB assembly, you must remove only the two black screws.
On the left USB assembly, you must remove the two black screws and the bottom silver screw.
On the right USB assembly, you must remove the two black screws and the top silver screw.
If you need to remove the left top assembly:
Top USB assembly
5. If you need to remove the left USB assembly:
Left USB assembly
USB port assembly 45
