HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 105
Destination Address IP address (version 4 or 6) or DNS host name of the host, switch,
or gateway receiving data. If you specified an IP address for the
SourceAddress, the DestinationAddress must use the same IP
version format.
Destination Prefix Length IPv4 or IPv6 subnet mask length. IPv4 [0..32], IPv6 [0..128]
Destination Port Destination port number (1–65535)
Protocol Protocol or application to which to apply IP security. Enter a
keyword for one of the following protocols or an integer (0-255):
• Internet Control Message Protocol for IP version 4 (ICMP)
• Internet Control Message Protocol for IP version 6 (ICMPv6)
• Internet Protocol, version 4 (IPv4)
• Transmission Control Protocol (TCP)
• User Datagram Protocol (UDP)
• Any protocol
• 0–255
IcmpV6Type ICMP number (0–255) if the protocol is ICMPv6.
Direction Direction of the data traffic to which to apply the policy:
In—Data entering the destination
Out—Data leaving the source
Priority Controls the relative ordering of this policy within the SPD
Action Processing to apply to data traffic:
• Discard—Unconditionally disallow all inbound or outbound
data traffic.
• None—Allow all inbound or outbound data traffic without
encryption or decryption.
• Ipsec—Apply IP security to inbound and outbound data traffic.
Protection Desired Type of IP security protection to apply:
• AH—Authentication Header
• ESP—Encapsulating Security Payload
• Both—Apply both AH and ESP protection
ahRuleLevel Rule level to apply for AH protection:
• Default
• Use—Use IPsec if corresponding SAD entry found, don't use
IPsec if corresponding SAD entry not found.
• Require—Use IPsec if corresponding SAD entry found, don't
communicate at all if corresponding SAD entry not found.
espRuleLevel Rule level to apply for ESP protection:
• Default
• Use
• Require
Table 17 Create IP Security Policy dialog box fields (continued)
Field Description
