Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly subcomponents on page 20.
(2) Top cover with keyboard (includes keyboard cable):
For a list of keyboard country codes, see Top cover with keyboard on page 67.
In aqua blue nish 917042-xx1
In jet black nish 917040-xx1
In snow white nish 912834-xx1
In violet purple nish 917041-xx1
In innity purple nish L21645-xx1
(3) TouchPad (includes bracket and double-sided adhesive):
NOTE: The TouchPad spare part kit does not include the TouchPad cable. The TouchPad cable is available using
spare part number 906781-001.
In aqua blue nish 911119-001
In jet black nish 911118-001
In snow white nish 912835-001
In violet purple nish 906786-001
In innity purple nish L21648-001
(4) TouchPad bracket (included in the TouchPad spare part kit)
(5) TouchPad cable (includes double-sided adhesive) 906781-001
(6) RTC battery (includes cable and double-sided adhesive) 818125-001
(7) Power connector cable 913730-001
(8) Hard drive (500-GB, 5400-rpm, SATA, 7.0-mm)
NOTE: The hard drive spare part kit does not include the hard drive bracket, hard drive
cable, or screws. The hard drive bracket, hard drive cable, and screws are included in
the Hard Drive Hardware Kit, spare part number 906770-001.
778186-005
Hard Drive Hardware Kit, includes: 906770-001
(9) Hard drive bracket
(10) Hard drive cable
Hard drive bracket screws (not illustrated)
(11) Battery (3-cell, 40-WHr, 3.615-AHr, Li-ion; includes cable) 844201-856
(12) Speakers (includes left and right speakers and cables) 906785-001
(13) System board (includes replacement thermal material and equipped with the following processors):
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Intel Pentium N3710 processor, 32-GB of eMMC system storage 910147-xx1
Computer major components 17
