Display assembly subcomponents
Item Component Spare part number
(1) Display panel assembly (includes bezel, panel, and TouchScreen board):
11.6-in, HD, WLED, AntiGlare (1366×768), slim (3.0-mm), SVA, eDP 906791-001
11.6-in, HD, WLED, AntiGlare (1366×768), slim (3.0-mm), IPS/UWA, eDP 906792-001
(2) Webcam/microphone module (includes double-sided adhesive) 907345-001
(3) TouchScreen board cable 910163-001
(4) Display panel cable (includes webcam/microphone module cable): 906776-001
(5) G-sensor module (includes double-sided adhesive) 906774-001
(6) G-sensor module cable 906778-001
(7) Display hinges (2, include left and right display hinges) 906771-001
(8) Display hinge covers (2, include left and right display covers)
20 Chapter 3 Illustrated parts catalog
