TouchPad cable
Description Spare part number
TouchPad cable (includes double-sided adhesive) 906781-001
Before removing the TouchPad cable, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 28).
5. Remove the battery (see Battery on page 30).
Remove the TouchPad cable:
1. Release the ZIF connector (1) to which the TouchPad cable is attached, and then disconnect
the TouchPad cable from the system board.
2. Release the ZIF connector (2) to which the TouchPad cable is attached, and then disconnect
the TouchPad cable from the TouchPad.
3. Remove the TouchPad cable (3).
Reverse this procedure to install the TouchPad cable.
52 Chapter 5 Removal and replacement procedures
