Memory module
Description Spare part
number
Memory module, 4 GB (PC3L-1600) for use with Celeron N3050, Celeron N3060, and Pentium N3710 processors 691740-005
Memory module, 8 GB (PC3L-1600) for use with Celeron N3050, Celeron N3060, and Pentium N3710 processors 693374-005
Memory module, 4 GB (PC4-2400) for use in models with Celeron N4000 and Pentium N5000 processors 862397-855
Memory module, 8 GB (PC4-2400) for use in models with Celeron N4000 and Pentium N5000 processors 862398-855
Before removing the memory module, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 28).
5. Disconnect the battery cable from the system board (see Battery on page 30).
Remove the memory module:
1. Remove the memory module shield.
The memory module shield is available using spare part number 910157-001.
2. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
Component replacement procedures 33
