TouchPad
NOTE: The TouchPad spare part kit includes the TouchPad bracket.
NOTE: The TouchPad spare part kit does not include the TouchPad cable. Refer to TouchPad cable
on page 52 for TouchPad cable removal instructions. The TouchPad cable is available using spare part number
906781-001.
Description Spare part number
TouchPad in aqua blue nish 911119-001
TouchPad in jet black nish 911118-001
TouchPad in snow white nish 912835-001
TouchPad in violet purple nish 906786-001
TouchPad in innity purple nish L21648-001
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 28).
5. Remove the battery (see Battery on page 30).
Remove the TouchPad:
1. Release the ZIF connector (1) to which the TouchPad cable is attached, and then disconnect
the TouchPad cable from the system board.
2. Remove the three Phillips PM2.0×2.3 screws (2) that secure the TouchPad to the keyboard/top cover.
3. Remove the six Phillips PM2.0×3.3 screws (3) that secure the TouchPad and the TouchPad bracket to
the keyboard/top cover.
4. Remove the TouchPad bracket (4).
Component replacement procedures 53
