Figure 1-3 HP t610 PLUS Thin Client rear panel components
(1) DVI-I connector for DVI-D and VGA output (7) PS/2 connectors (2)
(2) DisplayPort connector (8) Power cord retention slot
(3) Ethernet RJ-45 connector (9) Cable lock slot
(4) Universal serial bus (USB) connectors (2) 2.0 (10) Parallel connector
(5) Universal serial bus (USB) connectors (2) 3.0 (11) PCI-Express expansion slot
(6) Serial connector (12) Power connector
4 Chapter 1 Product features
