HP t610 Series User Manual

Removing and replacing the side access panel and metal
side cover
Removing the side access panel
WARNING! Before removing the side access panel, ensure that the thin client is turned off and the
power cord is disconnected from the electrical outlet.
To remove the left or right access panel:
1. Remove the stand, if it is installed. See
Removing the stand on page 7 for more information.
2. Press the tab on the bottom cover (1), and then slide the cover back (2) and lift it off the chassis.
Figure 2-1 Removing the bottom cover
3. Lay the thin client on its side on a secure working surface.
●
Remove the right side access panel to remove or install a SODIMM.
●
Remove the left side access panel to:
◦ Remove or replace the battery
◦ Install or remove a flash memory module
◦
Install or remove an internal hard drive
◦
Install or remove a PCI Express card
Removing and replacing the side access panel and metal side cover 11

HP t610 Series Specifications

General

Power Supply	65W external power adapter
Processor	AMD G-T56N APU with Radeon HD 6320 Graphics (1.65 GHz, 1 MB L2 cache)
Graphics	AMD Radeon HD 6320 Graphics
Memory	4 GB DDR3 SDRAM
Storage	500 GB HDD
Networking	Gigabit Ethernet
USB Ports	6 x USB 2.0 (2 front, 4 rear)
Operating System	HP ThinPro, Windows Embedded Standard 7
Chipset	AMD A55E
Ports	1 serial, 1 parallel
