HP t610 Series User Manual

Installing the stand
If the thin client will be installed in an vertical orientation and it will not be mounted, the stand should
be installed for stability.
To install the stand:
1. Turn unit upside down.
2. Locate the slots on the bottom of the unit into which the tabs on the stand fit.
3. Insert the tabs into the slots, and then slide the stand about 1.26 cm (1/2 inch) toward the front
of the unit until it locks into place.
Figure 1-5 Installing the stand
6 Chapter 1 Product features

HP t610 Series Specifications

General

Power Supply	65W external power adapter
Processor	AMD G-T56N APU with Radeon HD 6320 Graphics (1.65 GHz, 1 MB L2 cache)
Graphics	AMD Radeon HD 6320 Graphics
Memory	4 GB DDR3 SDRAM
Storage	500 GB HDD
Networking	Gigabit Ethernet
USB Ports	6 x USB 2.0 (2 front, 4 rear)
Operating System	HP ThinPro, Windows Embedded Standard 7
Chipset	AMD A55E
Ports	1 serial, 1 parallel
